CPM-158 CPM158 0.75kw Copper Wire Cast Iron Body Pump foot Household Centrifugal CPM single phase centrifugal pump are suitable for handling clean water not containing abrasive particles and fluids which are not chemically aggressive to the pump components.They are extremely reliable,simple to use,quiet and virtually maintence-free,finding many uses in domestic and civil applicaitons,and in particular the automatic
Series
CENTRIFUGAL PUMP
CPM158
·Flow rate up to 140L/min(8.4m3/h)
·Head up to 45m
·Suction lift up to 9m
· Fluid temperature up to 60℃
·Maximum ambient temperature 40℃
Single phase centrifugal pump220V/50Hz.Brass impeller,carbon steel motor shaft,with themal protector inside.Other model and material such as three phase,110V,60Hz,dual voltage,stainless shaft,ect,will be available upon
request.
CPM-158 CPM158 0.75kw Copper Wire Cast Iron Body Pump foot Household Centrifugal CPM Pump OEM
MOTOR BRACKET: cast iron.
IMPELLER: brass, centrifugal radial flow.
MOTOR SHAFT: AISI 314 stainless steel,
MECHANICAL SEAL: ceramic and graphite,
MOTOR: single phase centrifugal pump are coupled to an asynchronous, high efficiency TEK induction motor of suitable size, which is quiet, closed and externally ventilated, suitable for continuous duty.
The thermal cutout replay (motor protector ) is incorporated in all single phase motors.
Three phase motors require an adequate external motor protector, with connections according to current standards.
INSULATION: Class B (Class F)
PROTECTION: IP 44.
|
Model |
Power |
Q.Max |
H.Max |
S.Max |
In/Outlet |
Packing Dim. |
||
|
1-Phase |
3-Phase |
kw |
hp |
L/min |
m |
m |
mm |
mm |
|
CPM-130 |
CPMt-130 |
0.37 |
0.5 |
85 |
20 |
9 |
25X25 |
310x170x230 |
|
CPM-146 |
CPMt-146 |
0.55 |
0.8 |
90 |
25 |
9 |
25X25 |
340x175x235 |
|
CPM-158 |
CPMt-158 |
0.75 |
1 |
110 |
30 |
9 |
25X25 |
340x210x250 |
|
CPM-180 |
CPMt-180 |
1.1 |
1.5 |
120 |
40 |
9 |
40X40 |
380x250x320 |
|
CPM-200 |
CPMt-200 |
1.5 |
2 |
130 |
45 |
9 |
50X50 |
425x250x330 |
|
CPM-280 |
CPMt-280 |
2.2 |
3 |
140 |
50 |
9 |
50X50 |
425x250x330 |
FAQ
1.Who are we?
We are based in Zhejiang, China, start from 2000,sell to Mid East(40.00%),Africa(25.00%),Eastern Europe(20.00%),South Asia(10.00%),South America(5.00%).
2.How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.What can you buy from us?
Peripheral pump,Centrifugal pump,Submersible pump,Sewage pump,Booster pump .single phase centrifugal pump
4.Why should you buy from us not from other suppliers?
ZHEJIANG TANDI PUMP TECHNOLOGY CO,.LTD is a professional manufacturer with its own export right. We focus on the development and production of water pump for more than 15 years. We specialize in the production of vortex pumps and centrifugal pumps.
5.What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,
Language Spoken:English,Chinese,German,Russian
If you want to know more single phase centrifugal pump, please contact us immediately！！！
